Frame
FAT 4, 6061 T4-T6 alloy, variable thickness hydroformed tubes, tapered headtube 1"1/8-1"1/2, Bosch PowerTube battery integration (Horizontal), compatible with 26 x 4.8 tires, 12x197mm rear hub
Fork
Manitou, Mastodon Comp Extended, external compression and rebound adjustment, 100mm travel, 15x150mm
Motor
Bosch, Performance Line CX, 250W, Smart System, 85Nm
Battery
Bosch, PowerTube 625Wh, horizontal, Smart System
Remote
Bosch, Purion 200, Smart System, compact, color screen, navigation, «Walk assist»
Modes
Eco, Tour+, eMTB, Turbo
Rear Derailleur
Shimano, Deore, RD-M5100-SGS, 11-speed
Chainring
Narrow-Wide, 34 teeth, FAT specific
Cassette
Shimano, Deore, CS-M5100, 11-speed, 11-51T
Chain
Sram, PC1110, 11-speed, 124 links
Shifter
Shimano, Deore, SL-M5100-IR, 11-speed
Cranks
Forged aluminum, 170mm, FAT specific, 30mm offset
Front brake
Shimano, BR-M6120, hydraulic disc, 4 pistons
Rear Brake
Shimano, BR-M6120, hydraulic disc, 4 pistons
Front Rotor
Shimano, 203mm
Front Hub
Moustache, 32H, 15x150mm, thru axle
Rear Hub
Moustache, 32H, 12x197mm, thru axle
Rims
Moustache, alloy 6061E, welded, 32 holes, 26", internal width 80mm
Tyres
Avant: Maxxis, Minion FBF, 26x4.80 // Arrière: Maxxis, Minion FBR, 26x4.80
Saddle
Moustache, Ergonomic
Seatpost
EXA, 900i, dropper w/remote lever, 31.6mm
Seatpost travel
S: 100mm ; M: 125mm ; L: 150mm
Seatclamp
Moustache, alloy, 34.9mm
Handlebar
Moustache, alloy, 760mm, 15mm rise, 9° backsweep, 5° upsweep
Stem
Moustache, 3D forged Aluminum, 60mm
Lock
- / Bosch Connect Module (BCM) compatible, with eBike Alarm function
Pedals
alloy platform with reflectors
Warranty
5 years frame and fork Moustache Bikes - 2 years motor, battery
Sizes
S (1,50 -1,68m) ; M (1,65 - 1,83m) ; L (1,81 - 1,95m)
