Frame
Game, 6061 T4-T6 alloy, w/160mm travel, Bosch PowerTube custom battery integration (horizontal), 12x148mm, Boost, motor cover w/cooling fins & chainguide
Fork
FOX, Float 38 Factory, GRIP2 w/HSC/LSC/HSR/LSR, 170mm travel, 15x110mm Boost, 44mm offset, mini-fender compatible
Shock
Moustache, Magic Grip Control 160, specific Air Shock w/ 2-position platform and dynamic control of rebound, Trunion mount, build-in 205x65mm, 160mm travel
Motor
Bosch, Performance Line CX, 250W, Smart System, 85Nm
Battery
Bosch, PowerTube 750Wh, horizontal, Smart System
Conditions
Maximum, calculated for a 70kg rider in ideal conditions
Display
Bosch, Kiox 300, Smart System, compact, color screen, customizable screens, Lock function (optional), «Walk assist», LED Remote bluetooth Modes: Eco, Tour+, eMTB, Turbo
Rear Derailleur
Shimano, XTR, RD-M9100-SGS, 12-speed
Chainring
Moustache, 34T, Narrow Wide
Cassette
Shimano, XT, CS-M8100 12-speed, 10-51T
Chain
Shimano, CN-M6100, 12-speed, 120 links
Shifter
Shimano, XT, SL-M8100, 12-speed
Cranks
FSA, forged + CNC aluminium, 165mm
Front brake
Shimano, XT BR-M8120, hydraulic disc, 4 pistons
Rear Brake
Shimano, XT, BR-M8120, hydraulic disc, 4 pistons
Front Rotor
Shimano, 220mm
Hubs
Front: Moustache by Mavic, 28H, Centerlock, 15x110mm, thru axle // Rear: Moustache by Mavic, 28H, ID360, 12x148mm, thru axle
Rims
Moustache, asymmetric, Just_Carbon, 28 holes, 29", internal width 30mm, mounted with Tubeless valves & flap, triple thickness spokes, brass nuts with locking "Blue Nylon" insert
Tyres
Maxxis, Assegai, 29x2.50, foldable, 3C MaxxTerra / EXO+ / TR (Tubeless Ready)
Saddle
Moustache, Sport, CrMo rails
Seatpost
KS, Lev Integra, dropper-post w/ Shimano remote lever, 31.6mm
Seatpost travel
S: 125mm
M: 150mm
L: 175mm
XL: 200mm
Seatclamp
Moustache, alloy, 36.8mm
Handlebar
Moustache, Just_Carbon, 780mm, 12mm rise, 9° backsweep, 4° upsweep
Stem
Moustache, alloy, CNC, 40mm
Headset
Acros, AZX-579, sealed bearings
Lock
- / Bosch Connect Module (BCM) compatible, with eBike Alarm function
Pedals
alloy platform with reflectors
Warranty
5 years frame and fork Moustache Bikes - 2 years motor, battery
Sizes
S (1,56 -1,72m) ; M (1,69 - 1,85m) ; L (1,82 - 1,98m) ; XL (1,95 - 2,11m)
Colors
Black Glossy / Black Mat
