Frame
Frame
Xroad, 6061 T4-T6 alloy, variable thickness hydroformed tubes, Bosch PowerTube battery integration (vertical), integrated cable routing
Suspension
Fork
SR Suntour, XCM ATB, preload adjustment, 80mm travel
Motor System
Motor
Bosch, Performance Line, 250W, Smart System, 75Nm
Battery
Bosch, PowerTube 500Wh, vertical, Smart System
Conditions
Maximum, calculated for a 70kg rider in ideal conditions
Display
Bosch, Intuvia 100, Smart System, compact, LED remote Bluetooth Modes: Eco, Auto, Sport, Turbo
Transmission
Rear Derailleur
Shimano, Altus, RD-R2000-SGS, 9-speed ; WI-BO035
Chainring
Narrow-Wide, 40 teeth
Cassette
Shimano, CS-HG201, 9-speed, 11-36T
Chain
KMC, X9, 9-speed, 120 links
Shifter
Shimano, Altus, SL-M2010-R, 9-speed
Cranks
Moustache, aluminium, 170mm
Brakes
Front brake
Shimano, MT200 or Alhonga HJ-472, hydraulic disc brake
Rear Brake
Shimano, MT200 or Alhonga HJ-472, hydraulic disc brake
Front Rotor
Shimano, 180mm
Wheels
Hubs
Front: Shimano, 32H, 9x100mm, QR (Quick Release) // Rear: Shimano, 32H, 9x135mm, QR (Quick Release)
Rims
Moustache, asymmetric, alloy 6061E, welded, 32 holes, 27.5", internal width 23mm
Tyres
Hutchinson, Python 2, 27.5x2.10
Cockpit
Seatpost
Moustache, alloy, 31.6mm, 350mm
Seatclamp
Moustache, alloy, 34.9mm
Handlebar
Moustache, ergonomic, alloy, 680mm, 25° backsweep
Stem
Moustache, alloy, adjustable, 90mm
Grips
Ergonomic, dual-density
Equipment
Front light
AXA, Blueline, 30 lux, powered by main battery
Rear light
Spanninga, Presto2Guard, powered by main battery
Lock
- / Bosch Connect Module (BCM) compatible, with eBike Alarm function
Kickstand
Moustache, adjustable
Mudguard
Moustache, alloy, double wall design, w/alloy stays
Carrier
Moustache, alloy, removable QL3 lateral fixation, MIK HD platform
Pedals
Resin platform with reflectors
Features
Sizes
S (1,49 -1,61m) M (1,59 - 1,76m) L (1,74 - 1,90m)
Warranty
Warranty
5 years frame and fork Moustache Bikes - 2 years motor, battery
