Frame
Lundi 20 mid step-over, 6061 T4-T6 alloy, hydroformed and extruded triple cavity tubes for optimal stiffness. Integrated cable routing. Optimal geometry for stable handling and great manoeuvrability. Mounting points for optionnal front carrier
Fork
Lundi, alloy w/integrated cable routing
Motor
Bosch, Cargo Line - 250W nominal power, max 600W, 85Nm - Assistance up to 400 % - Powerful - Natural - Quiet - Frictionless - Compact - Lightweight
Battery
Bosch, DualBattery, 2 x PowerPack 500Wh. Total: 1000Wh
Charger
Bosch, Fast Charger 6Ah, 3h half charge, 5.4h full charge
Display
Bosch, Intuvia central mount with separate control unit - 5 modes (Eco, Tour, Sport, Turbo, Off) - « Walk assist » - Information available offline - USB port to charge a phone, MP3 player, etc.
Rear Derailleur
Shimano, Deore, RD-M5120-SGS, 10-speed, Shadow + (better chain retention)
Front cog / Chainring
FSA, 48T Narrow Wide with chain guard - Direct mount
Cassette
Shimano, CS-M4100-10, wide range 11-46T
Chain
Shimano, HG40, 10-speed
Shifter
Shimano, Deore, Rapidfire Plus
Cranks
Moustache, aluminium, 170mm
Brakes
Magura, MT4, hydraulic disc brakes
Rotors Front/Rear (in mm)
Magura, MDR-C, e-bike specific, 203mm front and 180mm rear, for better heat dissipation and braking control
Hubs
Front: Moustache, 32H, 15x110mm, Boost / Rear: Moustache, 32H, 12x148mm, Boost
Rims
Moustache, asymmetric 20", alloy 6061E, welded, 32 holes, internal width 23mm
Tyres
Kenda, 20x2.3, heavy load compatible, up to 100kg per tire
Saddle
Selle Italia, Essenza + Moderate
Seatpost
Moustache, suspension + dropper, alloy 34.9mm, 100mm drop, 40mm travel, comfort and security
Seatclamp
Moustache, key tightening
Handlebar
Moustache, Lundi custom ergonomic, alloy
Headset
FSA, No 28/41 integrated
Grips
Ergonomic, dual-density
Front light
AXA, Blueline, 30 lux, powered by main battery
Rear light
AXA, Duo Flat Signal, increased brightness under deceleration, powered by main battery
Kickstand
Moustache, central rear, wide stance for better stability
Mudguard
Front: Moustache, alloy, double wall design, w/alloy stays and mudflap / Rear: PP, 180° lateral protection
Rear carrier
Moustache, alloy, exclusive longtail design w/ integrated footrests. Removable side fastenings for QL3 luggage. Platform with multiple MIK HD 27kg system to rapidly attach all compatible accessories, bags and child seats. ALBERT protection bar for children safety (recommended height between 110-140cm. Smaller children require adapted baby seats)
Front Carrier
Optional extra: Moustache, alloy, compatible with MIK baskets and accessories. Available in 2 sizes
Pedals
Wide platform, anti-slip, alloy with reflectors
Warranty
5 years frame and Moustache Bikes fork - 2 years motor, battery (or 500 cycles) and accessories
Sizes
One size fits all (size 39, suitable for approximately a 1,55m to 1,90m rider)
