Frame
: Spark 3 Carbon / IMP technology / HMX BB92 / Carbon SMC Link / Carbon swingarm SW dropouts for Boost 148x12mm TBC Trunnion box construction custom Chainguide
Rear Shock: FOX NUDE Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout - Traction Control -Descend DPS / EVOL / Kashima / Reb. Adj. Travel 120 - 85 - Lockout / 165X45mm
Forks
: FOX 34 Float Factory Air / Kashima FIT4 3-Modes with low speed adj. / 15x110mm QR axle tapered steerer / Reb. Adj. / Lockout / 120mm travel
Rear Derailleur
: Sram XX1 / Eagle 12 Speed
Front Derailleur
: SCOTT Chainguide
Shifters
: Sram XX1 Trigger
Chainset
: Sram XX1 Eagle GXP Boost PF Carbon crankarm QF 168 / 700 Series: 34T / 900 Series: 32T
Bottom Bracket
: Sram GXP PF integrated / shell 41x92mm
Chain
: Sram PCXX1 Eagle
Freewheel/Cassette
: Sram XX1 / XG1299 / 10-50 T
Headset
: Syncros FL1.5 Drop in / Tapered 1.5" - 1 1/8" Ti bearing diameter size 42mm and 52mm
Stem
: Syncros FL1.5 / Alloy 2014 integrated Spacer & Top Cup / 31.8mm / 6deg / 1 1/8" Garmin mount
Handlebars
: Syncros FL1.0 SL Carbon T-Bar T shape flat / 9deg / 740mm Syncros Pro lock-on grips
Brakes
: Sram Level Ultimate Disc 180mm F & R / Centerline CLX Rotor
Rims
: Syncros XR1.0 Carbon / 28H / Carbon rim tubeless ready
Front Hub
: Syncros XR1.0 CL / 15x110mm made by DT Swiss
Rear Hub
: Syncros XR1.0 CL / Boost 148x12mm RWS w/removable Lever / 36T Rachet System / XD made by DT Swiss
Spokes
: DT Swiss Aero Comp
Tyres
: Maxxis Forekaster / 2.35 / 120TPI Kevlar Bead TR Tubeless Ready / EXO / 3C maxx speed Schwalbe EVO Tubes
Saddle
: Syncros XR1.0 SL / Carbon rails
Seatpost
: Rock Shox Reverb Stealth inside hydraulic remote system 31.6mm / S size 100mm / M, L & XL 125mm
Miscellaneous
Remote System: SCOTT TwinLoc Technology / below Bar Remote 3 modes / integ. Grip clamp
