FRAME
Ransom Alloy SL 6011, Custom butted / VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj., TBC Trunnion box construction / Boost 12x148mm
FORK
RockShox Domain R Solo Air, 15x110mm Maxle stealth axle, 42mm offset / Tapered Steerer, Reb. Adj. / 170mm travel
REAR SHOCK
X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 170-120-Lockout / 205X65mm
REMOTE SYSTEM
SCOTT TwinLoc TSP-R Technology, Suspension-Seatpost Remote, below Bar / 3 modes / integ. Grip clamp
REAR DERAILLEUR
Shimano Deore / 12 Speed
SHIFTERS
Shimano Deore SL-M6100-R / Rapidfire Plus
CRANKSET
Shimano FC-MT511-1, 32T
CHAINGUIDE
SCOTT Chainguide
BB-SET
Shimano BB-MT500-PA / shell 41x89.5mm
CHAIN
Shimano CN M6100
CASSETTE
Shimano Deore CS-M6100-12 / 10-51 T
BRAKES
Shimano MT520 Disc
ROTOR
Shimano SM-RT64 / CL / 203/F and 180/R
HANDLEBAR
Syncros Hixon 1.5 Rise / Alloy 20140D.B., 20mm rise / 8° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros XM1.5 / Alloy 6061, integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
SEATPOST
Syncros Duncan 2.5 Dropper Post, 31.6mm / S 125mm / M 150mm / L & XL 170mm
SEAT
Syncros Kaslo 2.0, Crmo Rails
HEADSET
Syncros OE Press Fit E2 / Tapered 1.5"-1 1/8", OD 50/62mm / ID 44/56mm
HUB (FRONT)
Shimano HB-MT410-B CL / 15x110mm
HUB (REAR)
Shimano FH-MT410-B CL / Boost 12x148mm / Micro Spline
SPOKES
Stainless Black 15G / 1.8mm
RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint, Tubeless ready
FRONT TIRE
Maxxis Assegai / 2.6" / 60TPI Foldable, EXO / TR / Dual
REAR TIRE
Maxxis Dissector / 2.6" / 60TPI Foldable, EXO / TR / Dual
EXTRA
SRS Zeb Fender
APPROX WEIGHTS IN KG
15.95 (with tubes)
APPROX WEIGHTS IN LBS
35.16 (with tubes)
MAX. SYSTEM WEIGHT
128 kg
