Sizes
27.5": XS, S , 29": S, M, L
Colours
Pale Moss
Frame
ALUXX-grade aluminum, 130mm FlexPoint suspension, 12x148mm thru-axle, UDH interface
Fork
Giant STL 34 dual air, 140mm, 15x110, thru-axle
Shock
Crest FloTrac Elite TR, 2-position lockout, 210x52.5, custom tuned for Liv
Handlebar
Giant Contact TR35, 35mm XS:20mm rise / 760mm, S:20mm rise / 760mm, M:35mm rise / 760mm, L:35mm rise 800mm
Stem
Giant Contact SL 35 XS: 40mm, S: 50mm, M: 50mm, L: 50mm
Seatpost
Giant Contact Switch AT dropper, remote XS: 110-140mm travel / 30.9 x 395mm S: 110-140mm travel / 30.9 x 395mm M: 140-170mm travel / 30.9 x 470mm L: 140-170mm travel / 30.9 x 470mm
Saddle
Liv Contact Ergo Trail
Shifters
Shimano CUES SL-6000, 1x10
Front Derailleur
N/A
Rear Derailleur
Shimano CUES RD-U6000, Shadow +
Brakes
Tektro HD-M5141, hydraulic, TR-54, 6-bolt rotors [F]180mm, [R]180mm
Brake Levers
Tektro HD-M5141
Cassette
Shimano CUES, CS-LG300, 11x48
Chain
KMC X-11
Crankset
Shimano CUES FC-U6000, XS: 165mm, S: 165mm, M: 165mm, L: 165mm, 34T for 27.5", 32T for 29"
Bottom Bracket
Shimano, threaded
Rims
Giant AM30 alloy rim
Hubs
[F] Giant MTB alloy, 6-bolt [R] Giant MTB alloy, 6-bolt, HG driver body
Spokes
stainless, 28, J-bend
Tyres
XS & S: [F] Maxxis Dissector 29x2.4, Dual, EXO, TR [R] Maxxis Minion DHR II 27.5x2.4, Dual, EXO, TR, tubeless M & L: [F] Maxxis Dissector 29x2.4, Dual, EXO, TR [R] Maxxis Minion DHR II 29x2.4, Dual, EXO, TR, tubeless
Extras
tubeless prepared, max tire size 2.5", max chainring size 34t
